power range:

60-300KVA

working method:

Three in three out online system

Performance Characteristics:

1, This series UPS All parts of the architecture are digitally controlled, UPS All performance indicators are excellent, The control system is more stable and reliable;

2, Hot swappable technology is used between modules and cabinets, UPS Modules can be added online, Pull out online, implement "zero" repair time;

3, adopt 19 Appearance of inch standard cabinet (1. 4 rice/2 Rice optional) , Can perfectly match the application environment of the computer room, Save the usable area of the computer room;

4, The number of redundant modules can be set arbitrarily, Can fully meet the high reliability requirements of critical loads on the power supply system;

5, Each module adopts an independent control system, UPS The module independently controls based on shared information;

6, Support parallel connection between cabinets, Parallel unit quantity 4 A cabinet;

7, Adopting decentralized bypass power supply, Each module is equipped with an automatic bypass switch and corresponding bypass current sharing inductance, Provides excellent current sharing performance for system bypass power supply;

8, multiple UPS When modules or cabinets are connected in parallel, Can share battery packs, Greatly reduces the number of battery configurations;

9, Users can set the charging current, constant current, Constant voltage and float charging modes can automatically switch smoothly;

10, The battery voltage can be configured arbitrarily±180Vdc~±300Vdc (30~50 Optional section) ;

11, LCD color screen display, Equipped with touch function, Chinese/ English bilingual options available; single module LCD/LED display;

12, An emergency shutdown is embedded on the monitoring unit panel (EPO) button, Press in emergency situations EPO Press the button to shut down urgently;

Application field:

Widely used in network management centers, Bank Securities, taxation, communication, postal service, SARFT, public security, traffic, electricity, medical, industrial control, Important data fields such as national defense.
